PostPosted: Sep 3rd, '18, 22:03
Offline
Admiral
User avatar

Joined: May 9th, '07, 02:05
Posts: 9863
Images: 1
Location: Bayside Melbourne
Has thanked: 241 times
Have thanks: 1039 times
We call them a mash hammer. Or a "thud".

_________________
A man's boat is his Castle. The Gippsland Lakes are my moat. Castle 650 #10, Roller Coaster.


Top
 Profile

PostPosted: Sep 13th, '18, 15:58
Offline
Able Skipper

Joined: Apr 19th, '09, 22:34
Posts: 1666
Location: Tanjil East - Moe
Has thanked: 402 times
Have thanks: 128 times
Hi All,
My Tohatsu 9.8 4st is finish and ready to be installed.
After I reshape the cowl, it is good fit.
I am going to write the manual for fitting Tohatsu 9.8 4 st to Noelex 25 without rudder extension on 2018 model.

Then I post it to people as a reference to help and to simplify this procedure.

Only one question I have and it is the propeller.
What type of propeller people use on this motor?
Regards Frank



For this message the author Frank Peters has received thanks: duncanhayward (Sep 13th, '18, 19:53)
  Rating: 4.76%
Top
 Profile

PostPosted: Sep 13th, '18, 18:21
Offline
Yachtmaster
User avatar

Joined: Oct 13th, '06, 10:51
Posts: 2094
Location: Bayswater North, Vic
Has thanked: 223 times
Have thanks: 80 times
Hi Frank,
I bought the high thrust propellor with the motor... Works well.
has four blades, numbers on it say 8.7 x 5 I think...

Cheers,
Marg

_________________
Marg
Special Edition NX 25,
LC 80 series
Bayswater North, Vic


Top
 Profile

PostPosted: Sep 13th, '18, 19:57
Offline
Able Skipper
User avatar

Joined: Mar 4th, '07, 11:02
Posts: 1136
Location: SE Melb
Has thanked: 132 times
Have thanks: 112 times
Marg is correctly. 4 blades at 8.75 diameter and 5" pitch.
A fantastic motor and propeller combination.
Frank you need to match the number of splines too.

_________________
Northerner28.


Top
 Profile

PostPosted: Sep 13th, '18, 21:40
Offline
Admiral
User avatar

Joined: May 9th, '07, 02:05
Posts: 9863
Images: 1
Location: Bayside Melbourne
Has thanked: 241 times
Have thanks: 1039 times
Adrian has a 4 blade prop on his Tohatsu 9.8 4st, it looks like a high thrust prop. We're transferring it from his old Noelex to his new one at the moment; I'm getting hands on experience with the motor mount in these boats...

_________________
A man's boat is his Castle. The Gippsland Lakes are my moat. Castle 650 #10, Roller Coaster.


Top
 Profile

PostPosted: Sep 13th, '18, 22:18
Offline
Able Skipper

Joined: Apr 19th, '09, 22:34
Posts: 1666
Location: Tanjil East - Moe
Has thanked: 402 times
Have thanks: 128 times
Hi Marg and All
And thanks to your information. My motor come with mark 8.5 - 3 blades 8.9 x 8.3. I will try it and possibly get high trust if it’s not suitable.
Regards Frank


Top
 Profile

PostPosted: Sep 20th, '18, 22:40
Offline
Able Skipper

Joined: Apr 19th, '09, 22:34
Posts: 1666
Location: Tanjil East - Moe
Has thanked: 402 times
Have thanks: 128 times
Hi All,
Today I finally put the Tohatsu 9.8 4 st in my Noelex.
To lift the motor and drop it in took only 15 min, but before that 5 weeks to figure out what to cut and reset.
To do it again would take me one day.
So motor is in and it is perfect.
I have clearance under rudder stock and I rest the linkages for locking the mounting board. I am very happy and fitting Tohatsu 4 st in Noelex without extension is reality.
I have standard prop, and I may modify it later if necessary for better reverse.
Also my dealer in Bairnsdale told me not to buy Tohatsu high trust prop, if I need it, buy Solarex after market, much cheaper.
They also have Tohatsu 9.8 4st with remotes in the shop for good price if somebody is interested.
So if everything goes well we will be on the water on Cup Day.
If anybody needs advice on fitting Tohatsu, send me email.
Regards Frank


Top
 Profile

PostPosted: Sep 20th, '18, 23:50
Offline
Admiral
User avatar

Joined: May 9th, '07, 02:05
Posts: 9863
Images: 1
Location: Bayside Melbourne
Has thanked: 241 times
Have thanks: 1039 times
Prop chart for the Tohatsu 9.8:

Attachment:
Toh98Props.gif [ 76.06 KiB | Viewed 137 times ]


Adrian has the 4 blade, 8.7x7 prop on a Noelex.

_________________
A man's boat is his Castle. The Gippsland Lakes are my moat. Castle 650 #10, Roller Coaster.


Top
 Profile

PostPosted: Sep 21st, '18, 22:07
Offline
Able Skipper

Joined: Apr 19th, '09, 22:34
Posts: 1666
Location: Tanjil East - Moe
Has thanked: 402 times
Have thanks: 128 times
Hi All,
I have considered modification of the propeller by drilling the holes for exhaust escape.

I don’t have the specification and Wanton promise to send it to me.

But as far as today I don’t have it.

Maybe he got confused about the drilling and sent it to EHarmony.
So I am still waiting.

Regards Frank


Top
 Profile

PostPosted: Sep 21st, '18, 22:50
Offline
Yachtmaster
User avatar

Joined: Nov 28th, '06, 08:36
Posts: 2467
Location: Sunbury Vic
Has thanked: 567 times
Have thanks: 275 times
My apologies Frank. I have been caught up in life's business. I will attend to your needs tomorrow.

_________________
Ed
Wanton C22/110
All I wanna do is sail
http://www.baysidetrailableyachtclub.com
Photo shows Wanton at Nara Inlet, Whitsundays, Qld.


Top
 Profile

PostPosted: Sep 23rd, '18, 18:32
Offline
Able Skipper

Joined: Apr 19th, '09, 22:34
Posts: 1666
Location: Tanjil East - Moe
Has thanked: 402 times
Have thanks: 128 times
Hi All,
I did not like Tohatsu 9.8 4 st tiller to stick out and make it difficult getting in and out of the boat.
So I took the motor out of the boat again for more modifications.
I removed the tiller and consider two options.
One to cut and shorten tiller by 100 mm and weld it, or shift it to other side. I did not like any of those options.
So next morning I decided to make small leaver and linkage to carby.
It is straight forward, I drill the hole next to choke and tomorrow I start on the leaver with red ball on the top.
After that I would like to separate output wire of the charging coil and take it through to my regulator already on the boat.
It is slow process, but in bad weather is OK.
Regards Frank


Top
 Profile

PostPosted: Sep 24th, '18, 19:40
Offline
Able Skipper

Joined: Oct 26th, '09, 22:20
Posts: 787
Location: Brisbane
Has thanked: 2 times
Have thanks: 144 times
Bye bye Warranty!


Top
 Profile

PostPosted: Sep 24th, '18, 21:25
Offline
Admiral

Joined: Nov 5th, '06, 13:07
Posts: 5815
Images: 12
Has thanked: 1286 times
Have thanks: 607 times
Frank, something like this might be useful.

https://www.ebay.com.au/itm/LAWN-MOWER- ... 2a898b9d40

_________________
RL24 Mk4 cruiser Mariner 5 2 stroke

A bad day in the Whitsundays is better than a good day at work. Unless you work in the Whitsundays.


Top
 Profile

PostPosted: Sep 24th, '18, 21:51
Online
Able Skipper

Joined: Oct 31st, '09, 17:12
Posts: 1117
Location: BrisVegas
Has thanked: 118 times
Have thanks: 58 times
I still believe Frank would go well with this.

https://rover.ebay.com/rover/0/0/0?mpre ... 2220040526


Top
 Profile

PostPosted: Sep 24th, '18, 21:54
Offline
Able Skipper

Joined: Apr 19th, '09, 22:34
Posts: 1666
Location: Tanjil East - Moe
Has thanked: 402 times
Have thanks: 128 times
Hi All,

Thanks for the advice, I know I blow my warranty by modifying the outboard to suit my needs.
I always service my outboards myself, so it disqualified me anyway.
I have new throttle lever nearly finish, it fits next to gear shift.
There is not much room and 6mm ss rod with red ball on top fits neatly.
Hopefully I finish it tomorrow and then test it on the stand.
I am taking photos to put it on the post later on, only the final design probably mark 5.
Regards Frank


Top
 Profile

PostPosted: Sep 24th, '18, 22:25
Offline
Admiral
User avatar

Joined: May 9th, '07, 02:05
Posts: 9863
Images: 1
Location: Bayside Melbourne
Has thanked: 241 times
Have thanks: 1039 times
Tohatsu already have the solution you need.

_________________
A man's boat is his Castle. The Gippsland Lakes are my moat. Castle 650 #10, Roller Coaster.


Top
